Build passkey wallets

NVNM Chain NEXT is an L1 forked from Tempo. Tempo verifies passkey (WebAuthn/P256) signatures in the protocol itself, so you can turn a passkey into an account without a smart-contract wallet, bundler or seed phrase.

This guide explains how NVNM Chain supports passkeys. It then walks through the passkey wallet in the NVNM demo dApp. You learn how to create an account, store its public key, restore it in a new browser and sign transactions.

How passkeys work on the chain

Tempo's docs explain why passkeys need protocol support:

Current accounts are limited to secp256k1 signatures and sequential nonces, creating UX and scalability challenges. Users cannot leverage modern authentication methods like passkeys, applications face throughput limitations due to sequential nonces.

Tempo solves this with Tempo Transactions, "a new EIP-2718 transaction type" with type byte 0x76. The first native feature the Tempo Transaction specification lists is "WebAuthn/P256 signature validation - enables passkey signing". Tempo sums up what this means for wallets:

Tempo Transactions natively support secp256k1, P256, and WebAuthn signatures. The protocol verifies these signatures directly, so passkey authentication works without custom contracts.

— Tempo docs: EIP-4337 comparison

The demo dApp describes its passkey account the same way: "a chain-native WebAuthn P-256 account" (apps/web/README.md).

Signature types

"Four signature schemes are supported. The signature type is determined by length and type identifier" (specification). The spec also notes: "Different signature types incur different base transaction costs to reflect their computational complexity." The last column shows that base transaction cost, not the cost of the signature check alone. The secp256k1 base of 21,000 "Includes 3,000 gas for ecrecover precompile", and P256 adds "additional 5k for P256 verification":

A passkey produces a WebAuthn signature. Tempo's WebAuthn struct looks like this:

pub struct WebAuthnSignature {
    typeId: u8,                 // 0x02
    webauthn_data: Bytes,       // Variable length (authenticatorData || clientDataJSON)
    r: B256,                    // 32 bytes
    s: B256,                    // 32 bytes
    pub_key_x: B256,            // 32 bytes
    pub_key_y: B256             // 32 bytes
}

Source: Tempo Transaction specification.

Tempo also advises: "For TempoTransactions, wallets should send minimal authenticatorData (37 bytes, no AT/ED flags) to minimize gas costs and simplify parsing."

How a passkey becomes an address

For P256 and WebAuthn keys, Tempo derives the address from the public key alone:

function deriveAddressFromP256(bytes32 pubKeyX, bytes32 pubKeyY) public pure returns (address) {
    // Hash
    bytes32 hash = keccak256(abi.encodePacked(
        pubKeyX,
        pubKeyY
    ));

    // Take last 20 bytes as address
    return address(uint160(uint256(hash)));
}

Source: Tempo Transaction specification.

Two consequences follow for your app:

• You must keep the public key. Tempo's viem guide warns you to store it: "A passkey only stores its credential id on the device, not the public key. Because the account address is derived from the public key, you must store it yourself (in a database or local storage) when the credential is created, then resolve it via getPublicKey when restoring" (viem: Sign in with a passkey).
• One passkey is one account. The formula takes no chain ID. The demo dApp tells its users: "Your address comes from the passkey, so creating another makes a new, empty account... It's the same address on testnet and devnet, with a separate balance on each."

What the chain checks, and what it skips

Tempo's WebAuthn verification follows the Daimo P256 verifier approach. The challenge is the transaction hash, Base64URL-encoded, and the signed message is sha256(authenticatorData || sha256(clientDataJSON)).

Because the chain skips origin and RP ID checks, the chain does not bind a passkey to your domain. The browser does. Keep this in mind when you read the security notes.

Passkey prompts and access keys

With a passkey as the root key, every signature needs a passkey prompt. Tempo's Account Keychain specification says:

for an Account using a Passkey as its Root Key, the sender will subsequently be prompted with passkey prompts for every signature request. This can be a poor user experience for highly interactive or multi-step flows. Additionally, users would also see "Sign In" copy in prompts for signing transactions which is confusing.

Tempo's answer is access keys. The same page introduces "the Root Key being able to provision a scoped Access Key that can be used for subsequent transactions, without the need for repetitive end-user prompting." The AccountKeychain precompile at 0xAAAAAAAA00000000000000000000000000000000 manages them. Note one restriction: "Access-key-signed transactions cannot perform CREATE or CREATE2, including via factory contracts. Use a Root Key for deployments."

The SDKs to use

The demo dApp builds its passkey wallet on three TypeScript packages that carry Tempo support. Tempo's TypeScript SDK page links to the viem and wagmi integrations:

The demo dApp's passkey ceremony also uses ox 0.14.45 and webauthx 0.1.2, the versions accounts 0.18.4 resolves. Its pnpm-workspace.yaml pins wagmi, @wagmi/core, accounts, ox and webauthx to exact versions (viem is ^2.57.1), so re-test before you bump them.

Tempo's minimal setup registers the connector in a wagmi config:

import { createConfig, http } from 'wagmi'
import { tempo } from 'wagmi/chains'
import { webAuthn } from 'wagmi/tempo'

export const config = createConfig({
  connectors: [webAuthn()],
  chains: [tempo],
  multiInjectedProviderDiscovery: false,
  transports: {
    [tempo.id]: http(),
  },
})

Source: wagmi.sh/tempo.

By default the connector runs the passkey ceremony in the browser. Tempo says: "Use webAuthn({ authUrl: '/api/webauthn' }) if you want registration and authentication challenges to come from a server endpoint instead of the default local browser ceremony." To plug in your own ceremony, pass ceremony. The demo dApp does this.

Build the passkey wallet

The steps below follow the demo dApp's web app in apps/web. It is a React app with wagmi and Reown AppKit.

import { defineChain, type Address, type Hash } from "viem";
import { tempoModerato } from "viem/tempo/chains";

// ...

// Passkey (Tempo) accounts need Tempo's chain config: the formatters, serializers and prepare hook for its native
// transaction type (0x76), plus the signature-envelope `verifyHash`. Their requests carry Tempo `calls`, which
// viem's default formatter drops. viem doesn't export the config on its own, so take exactly these keys off a
// Tempo chain (the whole chain would bring Tempo's contracts and hardfork). Tempo's `blockTime` (1 s) puts viem's
// default polling at its 500 ms floor, which suits NVNM Chain's ~0.5 s blocks.
//
// ...
//
// `feeToken` and `hardfork` stay unset on purpose. A fee token in a request makes viem send browser wallets a 0x76
// transaction, which MetaMask can't sign; on the chain it turns their gas estimates into 0x76. Unset, the chain
// charges nUSD. NVNM Chain runs Tempo forks up to t11/t12, past viem's list (t6), and viem treats a fork it doesn't
// know as older than all of them; unset, it assumes the current rules.
const { blockTime, extendSchema, formatters, prepareTransactionRequest, serializers, verifyHash } =
  tempoModerato;
const tempoChainConfig = {
  blockTime,
  extendSchema,
  formatters,
  prepareTransactionRequest,
  serializers,
  verifyHash,
};

export const nvnmTestnet = defineChain({
  ...tempoChainConfig,
  id: 787_223,
  name: "NVNM Tempo Testnet 1",
  nativeCurrency: nUSD,
  rpcUrls: {
    default: {
      http: [import.meta.env.VITE_NVNM_TESTNET_RPC_URL || "https://rpc.nvnm.testnet.nvnmchain.io"],
      webSocket: ["wss://ws.nvnm.testnet.nvnmchain.io"],
    },
  },
  // ...
  testnet: true,
});

import { WagmiAdapter } from "@reown/appkit-adapter-wagmi";
import { Storage } from "accounts";
import { http, type Config, type Connector } from "wagmi";
import { webAuthn } from "wagmi/tempo";

import { recoveringCeremony } from "@/lib/passkey-ceremony";

import { nvnmDevnet, nvnmTestnet } from "./chains";
import { PASSKEY_RDNS, PASSKEY_STORAGE_KEY, WALLETCONNECT_PROJECT_ID } from "./constant";

const chains = [nvnmTestnet, nvnmDevnet] as const;

// ...

// Holds the passkey accounts and the public keys of passkeys used here (IndexedDB). The connector and the ceremony
// must share it: the next sign-in looks up the keys the ceremony recovers in it.
const passkeyStorage = Storage.idb({ key: PASSKEY_STORAGE_KEY });

// A chain-native account per passkey (WebAuthn P-256), verified by NVNM Chain itself. Every transaction asks for the
// passkey: no access keys, fee payer or relay.
const passkey = webAuthn({
  name: "Passkey",
  rdns: PASSKEY_RDNS,
  // Machine payments would replace `globalThis.fetch` to pay HTTP 402 responses from the passkey account.
  mpp: false,
  storage: passkeyStorage,
  // Signs in with passkeys this browser hasn't stored a key for (another device, cleared site data).
  ceremony: recoveringCeremony({ storage: passkeyStorage }),
});

export type PasskeyConnector = Connector<ReturnType<typeof webAuthn>>;

// Tells the passkey connector apart by type. That also works on the connector of the connection wagmi restores while
// it reconnects on load, but that one is a stub with only id, name, type and uid: call methods only on a connector
// from `useConnectors()`.
export function isPasskey(connector: Connector): connector is PasskeyConnector {
  return connector.type === webAuthn.type;
}

// Owns the wagmi config: the adapter builds it from these options (they're wagmi `createConfig` parameters) and adds
// AppKit's connectors — injected, EIP-6963 wallets and, with a project id, WalletConnect — at runtime.
export const wagmiAdapter = new NvnmWagmiAdapter({
  networks: [...chains],
  projectId: WALLETCONNECT_PROJECT_ID,
  connectors: [passkey],
  transports: {
    [nvnmTestnet.id]: http(),
    [nvnmDevnet.id]: http(),
  },
});

// The passkey wallet's reverse-DNS id. The accounts SDK announces its provider over EIP-6963 under this id, and wagmi
// skips an announced wallet whose rdns matches a configured connector, so the passkey isn't listed twice.
export const PASSKEY_RDNS = "io.nvnmchain.demo.passkey";
// Prefix of the passkey wallet's keys in IndexedDB (the accounts SDK's `tempo` database): its accounts and the public
// keys of passkeys used on this site.
export const PASSKEY_STORAGE_KEY = "nvnm-demo-dapp";

type Capabilities = NonNullable<Parameters<PasskeyConnector["connect"]>[0]>["capabilities"];

// ...

function PasskeyView({ onBack }: { onBack: () => void }) {
  // ...
  const passkey = useConnectors().find(isPasskey);
  // ...
  const connected = Boolean(useConnection().address);
  const connect = useConnect();
  const pending = connect.isPending;
  // The network the app is on, which the header's faucet link uses too. The passkey connects on it (the accounts
  // SDK would otherwise pick its own saved network), so the faucet linked below funds it where it lands.
  const chainId = useChainId();
  const error = walletErrorMessage(connect.error);

  // ...

  function connectPasskey(action: Action, capabilities: Capabilities) {
    if (!passkey || pending || connected) return;
    setStarted(action);
    connect.mutate({ connector: passkey, chainId, capabilities });
  }

  function create(event: SubmitEvent) {
    event.preventDefault();
    connectPasskey("create", { method: "register", name: name.trim() || APP_NAME });
  }

  // ...
}

const passkeysSupported = typeof window.PublicKeyCredential !== "undefined";

// `selectAccount` lets the browser offer every passkey saved for this site instead of the last one used.
const signIn = () => connectPasskey("signIn", { method: "login", selectAccount: true });

const transfer = useWriteContract();

// ...

transfer.mutate(
  {
    address: nUSD.address,
    abi: tip20Abi,
    functionName: "transfer",
    args: [recipient, amount],
    chainId: chain.id,
  },
  { onSuccess: () => setResultOpen(true) },
);

// Checked against every error in the `cause` chain, outermost first. Wallet, passkey and RPC failures arrive wrapped
// by viem, wagmi and the passkey provider: a cancelled passkey prompt, for example, is an RPC -32603 error caused by
// the browser's `NotAllowedError`, not a 4001 rejection.
const known: [matches: (error: ErrorLike) => boolean, message: string][] = [
  [
    (e) => e.name === "NotAllowedError",
    // The browser uses one error for cancel, timeout and a failed biometric check.
    "The passkey request was cancelled or timed out.",
  ],
  [(e) => isRejection(e) && !isMisreported(e), "Request rejected in your wallet."],
  [
    (e) => messageOf(e).includes("Unknown credential"),
    "This passkey's account isn't known here yet. Try signing in again.",
  ],
  [
    // Thrown by the passkey ceremony when two signatures don't agree on one public key.
    (e) => e.name === "PasskeyRecoveryError",
    "Couldn't recover the account for this passkey.",
  ],
  [
    // Creating a passkey the authenticator already holds for this site.
    (e) => e.name === "InvalidStateError",
    "A passkey for this site already exists on this device. Sign in with it instead.",
  ],
  [
    (e) => e.name === "SecurityError",
    "Passkeys need a secure (https) page on the site's own domain.",
  ],
  [(e) => e.name === "NotSupportedError", "This browser doesn't support passkeys."],
  // ...
];

Where the dApp stores passkey data

The dApp stores passkey data in IndexedDB, not localStorage. Storage.idb is the Accounts SDK's IndexedDB adapter. Tempo documents it as "the default storage for Provider.create in the browser" (Storage.idb).

The adapter writes to an IndexedDB database named tempo. It prefixes every key with options.key, which Tempo describes as "Useful when several apps share the same origin and you want to avoid key collisions."

With key: "nvnm-demo-dapp", the dApp's data lives under these keys:

The SDK also persists its provider state, such as the connected accounts, through the same storage adapter.

The key names come from the internals of accounts 0.18.4, which the dApp relies on. Tempo doesn't document them, so check them again when you upgrade the SDK.

Restore an account in a new browser

WebAuthn returns a passkey's public key only when the passkey is created. If a user signs in from another device with a synced passkey, or after clearing site data, the browser has no stored key. The SDK's local ceremony then fails with Unknown credential.

Tempo's guidance is to store the public key yourself, "in a database or local storage", and the Accounts SDK offers a server-backed ceremony for this. The demo dApp has no backend, so it uses its own technique instead. ECDSA public-key recovery yields two candidate public keys per signature. The dApp asks for a second signature from the same passkey, keeps the one key that both sets share, and stores it:

import { type Storage, WebAuthnCeremony } from "accounts";
import { Bytes, Hash, P256, PublicKey, Signature } from "ox";
import type { Hex } from "viem";
import { Authentication } from "webauthx/client";

// ...

// Where accounts 0.18.4's `WebAuthnCeremony.local` keeps its credential id → public key map (uncompressed P-256,
// hex). Recovered keys go into the same map, so the next sign-in on this device takes the local path.
const credentialsKey = "credentials";

// ...

// The accounts SDK's local ceremony, able to sign in with a passkey this browser has never seen.
//
// WebAuthn only returns a passkey's public key when it is created, and the local ceremony keeps it in this browser's
// storage, so a passkey synced to another device, or used after site data is cleared, fails with "Unknown credential".
// There is no backend to ask. Instead, ECDSA public-key recovery gives two candidate keys per signature; a second
// signature by the same passkey, over a fresh challenge, shares exactly one of them: the passkey's key.
export function recoveringCeremony({
  storage,
  rpId,
  sign = Authentication.sign,
}: RecoveringCeremonyOptions): Ceremony {
  const local = WebAuthnCeremony.local({ storage, rpId });
  // Candidates from a recovery whose second prompt failed, by credential id, so a retry needs a single prompt.
  const pending = new Map<string, readonly Hex[]>();

  async function storedKeys() {
    return (await storage.getItem<Record<string, Hex>>(credentialsKey)) ?? {};
  }

  async function remember(credentialId: string, publicKey: Hex) {
    await storage.setItem(credentialsKey, { ...(await storedKeys()), [credentialId]: publicKey });
    pending.delete(credentialId);
    return { credentialId, publicKey };
  }

  return WebAuthnCeremony.from({
    ...local,
    async verifyAuthentication(response) {
      // The local ceremony's `verifyAuthentication` is this lookup, but throws where an unknown key starts recovery. A
      // stored key must also have made this signature: any page on this origin can write the map, and a wrong entry
      // would otherwise give the wrong address on every sign-in. Recovery replaces it.
      const known = (await storedKeys())[response.id];
      if (known && signedBy(response, known))
        return { credentialId: response.id, publicKey: known };

      const candidates = recoverCandidates(response);
      const earlier = pending.get(response.id);
      const recovered = earlier && commonKey(earlier, candidates);
      if (recovered) return remember(response.id, recovered);

      // If this prompt is cancelled the error propagates and `pending` keeps these candidates.
      pending.set(response.id, candidates);
      const { options } = await local.getAuthenticationOptions({ credentialId: response.id });
      const second = await sign({ options });
      // From here a failure can't tell which signature was wrong, so a retry starts over.
      pending.delete(response.id);
      if (second.id !== response.id) {
        throw new PasskeyRecoveryError(
          `Expected a second signature from passkey ${response.id}, got one from ${second.id}.`,
        );
      }
      const publicKey = commonKey(candidates, recoverCandidates(second));
      if (!publicKey) {
        throw new PasskeyRecoveryError(
          `The two signatures from passkey ${response.id} don't share a public key.`,
        );
      }
      return remember(response.id, publicKey);
    },
  });
}

// What a WebAuthn authenticator signs: sha256(authenticatorData ‖ sha256(clientDataJSON)).
function signedPayload(response: AuthenticationResponse) {
  const { authenticatorData, clientDataJSON } = response.metadata;
  return Hash.sha256(
    Bytes.concat(Bytes.fromHex(authenticatorData), Hash.sha256(Bytes.fromString(clientDataJSON))),
  );
}

// ...

// The public keys that could have produced this assertion's signature, one per y-parity of the curve point R, in the
// format the SDK stores. Parities that don't yield a point are skipped.
function recoverCandidates(response: AuthenticationResponse): Hex[] {
  const payload = signedPayload(response);
  const { r, s } = Signature.fromHex(response.signature);
  const candidates: Hex[] = [];
  for (const yParity of [0, 1]) {
    try {
      candidates.push(
        PublicKey.toHex(P256.recoverPublicKey({ payload, signature: { r, s, yParity } })),
      );
    } catch {
      // No curve point for this parity.
    }
  }
  return candidates;
}

// The one key both candidate sets share. Two shared keys mean the second signature repeats the first (the same r and
// s, up to the sign of s, over the same payload), which doesn't single out a key, so that counts as no match.
function commonKey(a: readonly Hex[], b: readonly Hex[]): Hex | undefined {
  const common = a.filter((key) => b.includes(key));
  return common.length === 1 ? common[0] : undefined;
}

View on GitHub: apps/web/src/lib/passkey-ceremony.ts

Here is what this means for your users:

• In a browser that already stores the key, sign-in takes one prompt. The ceremony still checks that the stored key made the signature, because "any page on this origin can write the map".
• In a new browser, sign-in takes two prompts. The dApp tells users: "In a browser you haven't used this passkey in, you'll confirm twice so we can recover your account."
• After recovery, the key is stored, so the next sign-in takes one prompt.

signedPayload computes the same message that Tempo's WebAuthn verifier checks: sha256(authenticatorData || clientDataHash).

Use a server-backed ceremony in production

The SDK's source describes WebAuthnCeremony.local as "a pure client-side ceremony for development and prototyping". For production, Tempo documents a server-backed ceremony. Mount Handler.webAuthn from accounts/server. Then point the connector at it with webAuthn({ authUrl: '/auth' }):

import { Handler, Kv } from 'accounts/server'

export const handler = Handler.webAuthn({
  kv: Kv.memory(),
  origin: 'https://app.example.com',
  rpId: 'example.com',
})

Tempo warns: "Kv.memory() is fine for local development and tests, but not for production. Use a persistent Kv adapter instead." Source: WebAuthn adapter guide.

Security and operational notes

Passkeys are bound to the domain

The browser binds every passkey to an RP ID. In the demo dApp, the RP ID is the page's hostname. Its README explains the consequences:

Passkeys are bound to the domain. A passkey belongs to the hostname it was created on, so production passkeys belong to nvnm-chain.github.io, and localhost (dev and vp preview) has its own. Every NVNM-Chain GitHub Pages site shares that hostname and its storage: any of them can ask for these passkeys and, with the user's biometric, sign for their accounts, so only trusted repos should publish to the org's Pages. A custom domain avoids that, but moving the app to another domain orphans every existing passkey account: the passkey can't be used there, so the app can no longer sign for that address. Settle the domain before promoting passkeys.

— Demo dApp README.md

Tempo's Accounts SDK docs give the same warning about your choice of RP ID:

Choose rpId carefully before you ship. If you register with rpId: 'example.com', that credential can be used from app.example.com and other subdomains that satisfy WebAuthn's RP rules. But the reverse is not true: a passkey created with rpId: 'app.example.com' cannot later be used with rpId: 'example.com'.

— WebAuthn adapter: Origin and RP ID

Tempo also says: "Treat rpId like part of your public API. Changing it later can strand existing credentials and force users to register new passkeys."

The browser enforces this binding. NVNM Chain doesn't.

Serve passkeys from a secure origin

• Tempo says: "WebAuthn requires a secure context outside of localhost. Production passkey ceremonies will fail outright over HTTP."
• In development, open your app at localhost. The dApp's README warns: "an IP address such as 127.0.0.1 isn't a valid passkey domain, so passkeys fail there."
• localhost and your production host hold different passkeys, so they are different accounts.

Plan for lost passkeys

There is no seed phrase. The dApp warns its users: "If every copy of the passkey is lost or deleted, the account and its funds are gone. Passkeys synced by iCloud Keychain or Google Password Manager also work on your other devices signed in to the same Apple or Google account."

Tempo adds that "you should not assume every user has sync enabled or access to the same provider on every device. A user can also lose all registered authenticators at once." Tempo advises you to "Plan for multiple credentials per user from the start" (Account recovery).

Fund new accounts

A new passkey account is empty. The dApp tells users: "New passkey accounts start with 0 nUSD, and network fees are paid in nUSD." Point your users to a faucet:

• Testnet: nUSD faucet
• Devnet: nUSD faucet

The dApp uses nUSD, the TIP-20 at 0x20C0000000000000000000000000000000000000, as the fee token on both networks. To learn how fees work, see Token balances and fees. Check Network details for each faucet's current status.

Try it in the demo dApp

Learn more in the Tempo docs

• Tempo Transactions
• Tempo Transaction specification: signature types, address derivation and WebAuthn verification
• Account Keychain specification: access keys
• Tempo Transactions compared with EIP-4337
• Tempo TypeScript SDKs
• wagmi webAuthn connector
• viem: Sign in with a passkey
• Tempo Accounts SDK: WebAuthn adapter
• Tempo Accounts SDK: production checklist

Next steps
